ATEN PE4104 — 4‑Outlet Metered‑by‑Outlet Rack PDU (Remote Power Management, 1U, 15A, Network‑Managed)

Four outlets, each individually switchable and metered — the PE4104 gives you remote on/off/reboot per outlet, per-outlet current and energy monitoring, SNMP v3, SSH, and ATEN Eco Sensors integration in a 1U rackmount chassis. The step up from the PE4102 when you need to manage four devices instead of two from a single remote power unit.

⚠️ Available to Order — Ships within 3-5 Business Days. Contact us at Info@westcoastproductsupply.com or call 949-288-3497 to confirm availability before ordering.

The ATEN PE4104 is a network-managed, metered-by-outlet rack PDU designed for IT, AV, and edge-infrastructure environments that require remote power control, per-outlet energy monitoring, and secure, centralized management. With four individually monitored AC outlets, support for SNMP, HTTP/HTTPS, and integration with ATEN's Eco Sensors energy-management platform, the PE4104 delivers enterprise-grade visibility and control in a compact 1U form factor.

Ideal for MSPs, server rooms, AV racks, IDF closets, and remote sites where uptime and remote troubleshooting matter.

Key Features

• 4-Outlet Metered-by-Outlet PDU with individual outlet monitoring

• Remote power control (on/off/reboot per outlet)

• Network-managed via HTTP/HTTPS, SNMP v1/v2c/v3, Telnet, SSH

• Per-outlet current, voltage, power, and energy monitoring

• 1U rackmount design for server and AV racks

• Supports ATEN Eco Sensors for centralized energy management

• Overcurrent protection with circuit breaker

• Secure access with user accounts, SSL, and role-based permissions

• Event notifications via email, syslog, and SNMP traps

• Durable metal chassis for professional installations

Technical Specifications

• Outlets: 4 x IEC C13

• Input: IEC C14

• Max Load: 15A

• Form Factor: 1U rackmount

• Monitoring: Per-outlet metering (current, voltage, power, energy)

• Control: Individual outlet on/off/reboot

• Network Protocols: HTTP/HTTPS, SNMP v1/v2c/v3, Telnet, SSH

• Management: ATEN Eco Sensors compatible

• Security: SSL, user roles, password protection

• Enclosure: Metal

• Warranty: ATEN 2-Year Warranty

Ideal Use Cases

• MSP remote-management deployments

• Server rooms and IDF closets

• AV racks and control systems

• Edge compute and remote sites

• Power monitoring for compliance and reporting

• Automated reboot routines for network gear

What's Included

• ATEN PE4104 PDU

• Rackmount hardware

• Quick-start documentation

Compliance & Warranty

• UL / FCC / CE

• ATEN 2-Year Warranty
